30GF
Cummins
Cummins 30KW 37.5KVA 50HZ land diesel generator genset (4BT3.9-G1 )
| Type | Open land diesel generator set |
| Generator model | 30GF |
| Rated power | 30KW |
| Standby power | 33KW |
| Generator capacity | 37.5KVA |
| Factor | 0.8 lag |
| Frequency | 50HZ |
| Voltage | 400/230 |
| Current | 54A |
| Phase / connection | 3 phase 4 wire |
| Generator Weight | 1140KG |
| Size | 2200×940×1460（mm） |
| Engine | Cummins 4BT3.9-G1 |
| Rated power | 36KW |
| Standby power | 40KW |
| Bore*stroke | 102*120 (mm) |
| Speed | 1500RPM |
| Alternator | Marathon GM-30-4 |
| Excitation | Brushless & self-excited |
| Insulation | H |
| Protection | IP22/23 |
| optional alternator brand | Stamford, Leroy Somer, Farady,etc, |
Cummins 30KW 37.5KVA 50HZ land diesel generator genset (4BT3.9-G1 )
| Type | Open land diesel generator set |
| Generator model | 30GF |
| Rated power | 30KW |
| Standby power | 33KW |
| Generator capacity | 37.5KVA |
| Factor | 0.8 lag |
| Frequency | 50HZ |
| Voltage | 400/230 |
| Current | 54A |
| Phase / connection | 3 phase 4 wire |
| Generator Weight | 1140KG |
| Size | 2200×940×1460（mm） |
| Engine | Cummins 4BT3.9-G1 |
| Rated power | 36KW |
| Standby power | 40KW |
| Bore*stroke | 102*120 (mm) |
| Speed | 1500RPM |
| Alternator | Marathon GM-30-4 |
| Excitation | Brushless & self-excited |
| Insulation | H |
| Protection | IP22/23 |
| optional alternator brand | Stamford, Leroy Somer, Farady,etc, |
