Cummins 20KW 25KVA 60HZ land power generator genset set

Availability:
Quantity:
Inquire Add to Basket

  • 20GF
  • Cummins

Cummins 20KW 25KVA 60HZ land power generator genset  set


Type Cummins Land  generator genset
Generator   model20GF
Rated power20KW
Standby   power 22KW
Generator   capacity25KVA
Factor0.8 lag
Frequency60HZ
Voltage480/240V
Current36A
Phase /   connection3 phase 4 wire
Generator   Weight940KG
Size 2200×940×1460（mm）
Engine Cummins 4B3.9-G2
Rated power30KW
Standby   power 33KW
Bore*stroke102*120 (mm)
Speed1800RPM
Alternator Marathon GM-20-4
ExcitationBrushless &   self-excited
Insulation H
ProtectionIP22/23
optional   alternator brand Stamford, Leroy   Somer, Farady,etc,
