6CTAA8.3-C240
DCEC Cummins
DCEC Cummins 6CTAA8.3-C240 construction diesel engine motor 240HP 2200RPM
| Engine model | 6CTAA8.3-C240 (240HP 2200RPM) |
| Engine style | Cummins construction industrial diesel engine |
| Type | In-line,4 stroke,water cooling,Direct injection |
| Intake system | Turbocharged and Air to air aftercooled |
| Bore X Stroke | 114x135mm |
| Displacement | 8.3L |
| Governor ratio | 5% |
| Rotation | Clocewise (face to flywheel) |
| Rated power | 179KW /2200RPM (240HP /2200RPM) |
| Max torque | 1040N.m/1400RPM |
| Idle speed | 750RPM |
| Electrical system | 24V/12V |
| Fuel Consumption | 223g/kw.h |
| Net Weight | 604KG |
| Gross weight | 700KG |
| Overall Diemension(L*W*H) | 1240mm*780mm*1185mm |
| Package size(L*W*H) | 1450mm*900mm*1350mm |
| Max.Continuous Running Altitude | 2000m |
| Emission | China Nation II,Euro II |
| Application | Motor grader,truck crane,Drilling rigs,Air compressor,etc |
