DCEC Cummins 4BTAA3.9-C100 Construction diesel engine motor 100HP
DCEC Cummins 4BTAA3.9-C100 Construction diesel engine motor 100HP
Share to:

DCEC Cummins 4BTAA3.9-C100 Construction diesel engine motor 100HP

Quantity:
Inquire Add to Basket

  • 4BTAA3.9-C100
  • DCEC Cummins

DCEC Cummins 4BTAA3.9-C100  Construction diesel engine motor 100HP


Engine   model4BTAA3.9-C100   (100HP 2200RPM)
Engine styleCummins construction industrial diesel engine
TypeIn-line,4 stroke,water cooling,Direct injection
Intake system Turbocharged and Air to air aftercooled
Bore X Stroke102x120mm
Displacement3.9L
Compression   ratio17.3:1
Fuel systemP7100 injection pump   + RSV governor
Governor   ratio5%
RotationClocewise (face to   flywheel)
Rated power74KW/2200RPM   (100HP/2200RPM)
Max torque400N.m/1500RPM
Idle speed900RPM
Electrical   system24V/12V
Fuel   Consumption210g/kw.h
Net   Weight 388KG
Gross weight540KG
Overall   Diemension(L*W*H)867mm*544mm*988mm
Package   size(L*W*H)1110mm*910mm*1350mm
Max.Continuous   Running Altitude2000m
EmissionChina Nation II, Euro   II
ApplicationHydraulic   Excavator,Wheel loader,Roller,Air compressor,etc



Rekino Cummins

       Shanghai Rekino Engine Equipment Co.,Ltd is a professional diesel engine suplier. Cummins series engine are our main product. Rekino can provide all series Chinese Cummins engines, from 20HP to 2000HP. including DCEC, CCEC, XCEC, FOTON Cummins,and Guangxi Cummins industrial power engines. production kinds include, 4BTM, 6BT,6CT 6LT, QSB4.5, QSB6.7,QSL8.9,QSM11, M11, NT855, KTA19, KTA38,KTA50, QSK19,ISM11,ISL8.9,ISB4.5, ISB5.9, ISL9.5,ISZ13,ISF2.8,ISF3.8,ISG11,ISG12,etc.
