Cummins 150KW 188KVA 50HZ marine generator genset CCFJ150JW
| Type of Gen-set | Cummins marine diesel generator | |
| Generator model | CCFJ150JW | |
| Rated Capacity | (KVA) | 188KVA |
| Rated Power | (KW) | 150KW |
| Standby power | (KW) | 165KW |
| Diesel Engine | Cummins NT855-DM / 6LTAA8.9-GM200 | |
| Alternator | Marathon MP-H-150-4 or Sunvim SVH274 | |
| Engine power | (KW) | 180KW |
| Cooling Mode | Heat Exchanger Cooling | |
| Rated Voltage | (V) | 400V |
| Rated Current | (A) | 271A |
| Rated Frequency | (HZ) | 50HZ |
| Power Factor(Lagging) | 0.8 | |
| Phase & Connection | Three Phases & Three Wires, Y Connection | |
| Rated Speed | (RPM) | 1500RPM |
| Fuel Consumption | (g/kW.h) | ≤205 |
| Starting Mode | Electric Starting | |
| Weight of Gen-set | (KG) | 2400KG |
| Overall Dimension | (mm) | 2860*1300*1850mm |
| Certificate | CCS,IMO,BV,etc |
Cummins 150KW 188KVA 50HZ marine generator genset CCFJ150JW
| Type of Gen-set | Cummins marine diesel generator | |
| Generator model | CCFJ150JW | |
| Rated Capacity | (KVA) | 188KVA |
| Rated Power | (KW) | 150KW |
| Standby power | (KW) | 165KW |
| Diesel Engine | Cummins NT855-DM / 6LTAA8.9-GM200 | |
| Alternator | Marathon MP-H-150-4 or Sunvim SVH274 | |
| Engine power | (KW) | 180KW |
| Cooling Mode | Heat Exchanger Cooling | |
| Rated Voltage | (V) | 400V |
| Rated Current | (A) | 271A |
| Rated Frequency | (HZ) | 50HZ |
| Power Factor(Lagging) | 0.8 | |
| Phase & Connection | Three Phases & Three Wires, Y Connection | |
| Rated Speed | (RPM) | 1500RPM |
| Fuel Consumption | (g/kW.h) | ≤205 |
| Starting Mode | Electric Starting | |
| Weight of Gen-set | (KG) | 2400KG |
| Overall Dimension | (mm) | 2860*1300*1850mm |
| Certificate | CCS,IMO,BV,etc |
