CCEC Cummins KT38-GA G Drive diesel engine motor for genset generator 647KW 1500RPM

Quantity:
  • KT38-GA
  • CCEC Cummins

CCEC Cummins KT38-GA  G Drive diesel engine motor for genset generator  647KW 1500RPM


Engine   modelKT38-GA (647KW 1500RPM)
Engine styleCummins G-drive  diesel engine for generator
TypeV type,4 stroke,water cooling,Direct injection
Cylinders No.12 Cylinders
Intake systemTurbocharged
Bore X Stroke159x159mm
Displacement38L
Compression   ratio14.5:1
Fuel systemPT STC
Governor typeEFC
Governor ratio3%
RotationClocewise (face to   flywheel)
Prime   Unlimited time power (Engine)647KW/1500RPM
Standby power   (Engine)711KW/1500RPM
Prime   Unlimited time power (Generator) 580KW (725KVA) 50HZ
Standby power   (Generator) 640KW (800KVA) 50HZ
Cooling wayPositive water   cooling cycle
Lubricant   capacity114L
Coolant   capacity with radiator194L
Electrical   system24V
Fuel   Consumption210g/kw.h
Wet weight3954KG
Overall   Diemension(L*W*H)2260mm*1339mm*2332mm
RadiatorRadiator and fan are   additional
ApplicationDiesel generator, water pump set



Rekino Cummins

       Shanghai Rekino Engine Equipment Co.,Ltd is a professional diesel engine suplier. Cummins series engine are our main product. Rekino can provide all series Chinese Cummins engines, from 20HP to 2000HP. including DCEC, CCEC, XCEC, FOTON Cummins,and Guangxi Cummins industrial power engines. production kinds include, 4BTM, 6BT,6CT 6LT, QSB4.5, QSB6.7,QSL8.9,QSM11, M11, NT855, KTA19, KTA38,KTA50, QSK19,ISM11,ISL8.9,ISB4.5, ISB5.9, ISL9.5,ISZ13,ISF2.8,ISF3.8,ISG11,ISG12,etc.
