DCEC Cummins QSB3.9-C80-31 Construction diesel engine motor 80HP 2200RPM
| Engine model | QSB3.9-C80-31 (80HP 2200RPM) |
| Engine style | Cummins construction Industrial diesel engine |
| Type | In-line,4 stroke,water cooling,Direct injection |
| Cylinders No. | 4 Cylinders |
| Intake system | Turbocharged and intercooler |
| Bore X Stroke | 102x120mm |
| Displacement | 3.9L |
| Compression ratio | 16.6 |
| Fuel system | HPCR |
| Rotation | Closewise (face to flywheel) |
| Rated power | 60KW/80HP/2200RPM |
| Max torque | 350N.m/1600RPM |
| Idle speed | 750RPM |
| Electrical system | 24V/12V |
| Net Weight | 331KG |
| Overall Diemension(L*W*H) | 778mm*753mm*882mm |
| Package size(L*W*H) | 900mm*900mm*1000mm |
| Option parts | Air filter,exhaust pipe,bellow,silencer,radiator,control panel,etc |
| Emission | China stage III, EU Stage IIIA |
| Application | Wheel loader, hydraulic excavator, Motor grader,Air compressor,etc |
DCEC Cummins QSB3.9-C80-31 Construction diesel engine motor 80HP 2200RPM
| Engine model | QSB3.9-C80-31 (80HP 2200RPM) |
| Engine style | Cummins construction Industrial diesel engine |
| Type | In-line,4 stroke,water cooling,Direct injection |
| Cylinders No. | 4 Cylinders |
| Intake system | Turbocharged and intercooler |
| Bore X Stroke | 102x120mm |
| Displacement | 3.9L |
| Compression ratio | 16.6 |
| Fuel system | HPCR |
| Rotation | Closewise (face to flywheel) |
| Rated power | 60KW/80HP/2200RPM |
| Max torque | 350N.m/1600RPM |
| Idle speed | 750RPM |
| Electrical system | 24V/12V |
| Net Weight | 331KG |
| Overall Diemension(L*W*H) | 778mm*753mm*882mm |
| Package size(L*W*H) | 900mm*900mm*1000mm |
| Option parts | Air filter,exhaust pipe,bellow,silencer,radiator,control panel,etc |
| Emission | China stage III, EU Stage IIIA |
| Application | Wheel loader, hydraulic excavator, Motor grader,Air compressor,etc |
