CCFJ900JW
Cummins
Cummins 900KW 1125KVA 50HZ marine generator genset CCFJ800JW QSK38-DM
| Type of Gen-set | Cummins marine diesel generator | |
| Generator model | CCFJ900JW | |
| Rated Capacity | (KVA) | 1125KVA |
| Rated Power | (KW) | 900KW |
| Standby power | (KW) | 1000KW |
| Diesel Engine | Cummins QSK38-DM | |
| Alternator | Marathon MX-H-1000-4 or Sunvim SVH454 | |
| Engine power | (KW) | 984KW |
| Cooling Mode | Heat Exchanger Cooling | |
| Rated Voltage | (V) | 400V |
| Rated Current | (A) | 1624A |
| Rated Frequency | (HZ) | 50HZ |
| Power Factor(Lagging) | 0.8 | |
| Phase & Connection | Three Phases & Three Wires, Y Connection | |
| Rated Speed | (RPM) | 1500RPM |
| Fuel Consumption | (g/kW.h) | ≤205 |
| Starting Mode | Electric Starting | |
| Weight of Gen-set | (KG) | 7000KG |
| Overall Dimension | (mm) | 4100*1500*2500mm |
| Certificate | CCS,IMO,BV,etc |
Cummins 900KW 1125KVA 50HZ marine generator genset CCFJ800JW QSK38-DM
| Type of Gen-set | Cummins marine diesel generator | |
| Generator model | CCFJ900JW | |
| Rated Capacity | (KVA) | 1125KVA |
| Rated Power | (KW) | 900KW |
| Standby power | (KW) | 1000KW |
| Diesel Engine | Cummins QSK38-DM | |
| Alternator | Marathon MX-H-1000-4 or Sunvim SVH454 | |
| Engine power | (KW) | 984KW |
| Cooling Mode | Heat Exchanger Cooling | |
| Rated Voltage | (V) | 400V |
| Rated Current | (A) | 1624A |
| Rated Frequency | (HZ) | 50HZ |
| Power Factor(Lagging) | 0.8 | |
| Phase & Connection | Three Phases & Three Wires, Y Connection | |
| Rated Speed | (RPM) | 1500RPM |
| Fuel Consumption | (g/kW.h) | ≤205 |
| Starting Mode | Electric Starting | |
| Weight of Gen-set | (KG) | 7000KG |
| Overall Dimension | (mm) | 4100*1500*2500mm |
| Certificate | CCS,IMO,BV,etc |
