Cummins 64KW 60HZ marine generator genset CCFJ64JW 6BT5.9-GM100

Quantity:
  • CCFJ64JW 6BT5.9-GM100
  • Cummins

Cummins 64KW 60HZ marine generator genset  CCFJ64JW  6BT5.9-GM100


Type of   Gen-set
Cummins marine   diesel generator
Generator model
CCFJ64JW
Rated Capacity(KVA)80KVA
Rated Power(KW)64KW
Standby power(KW)72KW
Diesel Engine
Cummins   6BT5.9-GM100
Alternator
Marathon   MP-H-64-4 or Sunvim SVH224
Engine power (KW)100KW
Cooling Mode
Heat   Exchanger Cooling
Rated Voltage(V)440V
Rated Current(A)115A
Rated Frequency(HZ)60HZ
Power Factor(Lagging)
0.8
Phase & Connection
Three   Phases & Three Wires, Y Connection
Rated Speed(RPM)1800RPM
Fuel Consumption(g/kW.h)205
Starting Mode
Electric   Starting
Weight of Gen-set(KG)1230KG
Overall Dimension (mm)2210*770*1200mm
Certificate
CCS,IMO,BV,etc



Rekino Cummins

       Shanghai Rekino Engine Equipment Co.,Ltd is a professional diesel engine suplier. Cummins series engine are our main product. Rekino can provide all series Chinese Cummins engines, from 20HP to 2000HP. including DCEC, CCEC, XCEC, FOTON Cummins,and Guangxi Cummins industrial power engines. production kinds include, 4BTM, 6BT,6CT 6LT, QSB4.5, QSB6.7,QSL8.9,QSM11, M11, NT855, KTA19, KTA38,KTA50, QSK19,ISM11,ISL8.9,ISB4.5, ISB5.9, ISL9.5,ISZ13,ISF2.8,ISF3.8,ISG11,ISG12,etc.
