Cummins 400KW 500KVA 50HZ land diesel generator genset (KTA19-G4)

Availability:
Quantity:
Inquire Add to Basket

  • 400GF

  • Cummins

Cummins 400KW  500KVA 50HZ land diesel generator genset (KTA19-G4)


Type Cummins diesel   generator genset
Generator   model400GF
Rated power400KW
Standby   power 440KW
Generator   capacity500KVA
Factor0.8 lag
Frequency50HZ
Voltage400/230V
Current721A
Phase /   connection3 phase 4 wire
Generator   Weight3650KG
Size 3400*1250*1970（mm）
Engine Cummins KTA19-G4
Rated power448KW
Standby   power 504KW
Bore*stroke159*159 (mm)
Speed1500RPM
Alternator Marathon MP-400-4
ExcitationBrushless &   self-excited
Insulation H
ProtectionIP22/23
optional   alternator brand Stamford, Leroy   Somer, Farady,etc,
