CCEC Cummins KTA19-C600 construction diesel engine motor 600HP
Engine model | KTA19-C600 |
Engine style | Cummins construction industrial diesel engine |
Type | In-line,4 stroke,water cooling,Direct injection |
Cylinders No. | 6 Cylinders |
Intake system | Turbocharged and intercooled |
Bore X Stroke | 159x159mm |
Displacement | 19L |
Compression ratio | 13.9 |
Power / Speed | 448KW ( 600HP) / 2100RPM |
Torque / speed | 2237N.m /1500 RPM |
Fuel system | PT fuel system |
Governor ratio | 5% |
Rotation | Closewise (face to flywheel) |
Idle speed | 750RPM |
Electrical system | 24V/12V |
Fuel Consumption | 210g/kw.h |
Net Weight | 2073Kg |
Gross weight | 2123 Kg |
Overall Diemension(L*W*H) | 2151mm*966mm*1704mm |
Package size(L*W*H) | 2451mm*1300mm*2000mm |
Max.Continuous Running Altitude | 2000m |
Option parts | Air filter,exhaust pipe,bellow,silencer,radiator,control panel,etc |
Application | Highway construction machinery,Dumper,Drilling machine, etc |
