CCEC Cummins KT38-M800 (800HP 1800RPM ) marine propulsion diesel engine motor

Availability:
Quantity:
Inquire Add to Basket

  • KT38-M800
  • CCEC Cummins

CCEC Cummins KT38-M800  (800HP 1800RPM ) marine propulsion diesel engine motor


Engine   modelKT38-M800
StyleMarine diesel engine   (Main engine)
TypeV type, 12-Cylinder,   4-Stroke, 4-Valve
AspirationTurbocharged
Bore x stroke159x159mm
Displacement38 L
Compression   Ratio13.8
Rating typeCON
Power / Speed597 KW (800HP)   /1800RPM
RotationCounter clockwise   facing flywheel
Fuel   Consumption154 l/hr
Fuel systemPT
Dimension2844x1331x1909mm
Dry weight4154KG
EmissionCCS +IMO
Matching   gearbox  AdvanceHC400,HCD400A,HCT400A,etc
Matching   gearbox  FADAJ400A,JD400A,JT400A,etc
ApplicationFishing   vessel,Cargo,transport ship,working boat,Offshore project,etc.
