DCEC Cummins 6BTA5.9-C165 Construction diesel engine motor 165HP 2200RPM

Quantity:
  • 6BTA5.9-C165
  • DCEC Cummins

DCEC Cummins 6BTA5.9-C165  Construction diesel engine motor 165HP 2200RPM


Engine   model6BTA5.9-C165  (165HP 2200RPM)
Engine styleCummins construction industrial diesel engine
TypeIn-line,4   stroke,water cooling,Direct injection
Cylinders No.6 Cylinders
Intake system Turbocharged and Aftercooled
Bore X Stroke102x120mm
Displacement5.9L
Compression   ratio17.3:1
Fuel systemBYC PB injection pump   + RSV governor
Governor   ratio5%
RotationClocewise (face to   flywheel)
Rated power123KW/2200RPM   (165HP/2200RPM)
Max torque694N.m/1500RPM
Idle speed750RPM
Electrical   system24V/12V
Fuel   Consumption228g/kw.h
Net   Weight 443KG
Gross weight550KG
Overall   Diemension(L*W*H)1110mm*750mm*988mm
Package   size(L*W*H)1310mm*900mm*1400mm
Max.Continuous   Running Altitude2000m
Option   parts Air filter,exhaust   pipe,bellow,silecner,radiator,control panel,etc
ApplicationExcavator, Wheel   loader,Rig,Roller,Truck crane,motor grader,Milling,Air compressor,etc



Rekino Cummins

       Shanghai Rekino Engine Equipment Co.,Ltd is a professional diesel engine suplier. Cummins series engine are our main product. Rekino can provide all series Chinese Cummins engines, from 20HP to 2000HP. including DCEC, CCEC, XCEC, FOTON Cummins,and Guangxi Cummins industrial power engines. production kinds include, 4BTM, 6BT,6CT 6LT, QSB4.5, QSB6.7,QSL8.9,QSM11, M11, NT855, KTA19, KTA38,KTA50, QSK19,ISM11,ISL8.9,ISB4.5, ISB5.9, ISL9.5,ISZ13,ISF2.8,ISF3.8,ISG11,ISG12,etc.
