KTA19-P700
CCEC Cummins
CCEC Chongqing Cummins KTA19-P700 P Type pump stationary diesel engine motor 700HP 1800RPM
| Engine model | KTA19-P700 (700HP 1800RPM) |
| Engine style | Cummins P type diesel engine for water pump power unit |
| Type | In-line,4 stroke,water cooling,Direct injection |
| Cylinders No. | 6 Cylinders |
| Intake system | Turbocharged Aftercooled |
| Bore X Stroke | 159x159mm |
| Displacement | 19L |
| Compression ratio | 14.5:1 |
| Fuel system | PTG-VS |
| Rotation | Clocewise (face to flywheel) |
| Rated power (KW/HP/RPM) | 522KW/700HP/1800RPM |
| Peak torque (N.m/rpm) | / |
| Cooling way | Positive water cooling cycle |
| Lubricant capacity | 50L |
| Coolant capacity | 66L |
| Electrical system | 24V |
| Fuel Consumption | 210g/kw.h |
| Wet weight | 1927KG |
| Overall Diemension(L*W*H) | 2142mm*1067mm*1733mm |
| Radiator | Radiator and fan are additional |
| Application | Water pump set, Fire pump, Sandy pump,Air compressor.etc |
